SMC - Stopper Cylinders

SMC - Stopper Cylinders

มีทั้งหมด 4 รุ่น คือ

  1. Stopper Cylinder RSQ / RSDQ / RSG / RSDG
  2. Heavy Duty Stopper Cylinder RS2H
  1. Heavy Duty Stopper Cylinder RSH
  2. Escapements MIW / MIS

1) Stopper Cylinder RSQ / RSDQ / RSG / RSDG

SMC - Stopper Cylinder RSQ / RSDQ / RSG / RSDG
SMC - Stopper Cylinder RSQ / RSDQ / RSG / RSDG

Features | Stopper Cylinder RSQ / RSDQ / RSG / RSDG

  • A wide range of models are available, so it is possible to select a cylinder that meets your needs. Realizes the labor saving and automation of conveyor lines
  • With auto switch (RSDQ series: RSDQ, RSDG series: RSDG)
ดาวน์โหลดไฟล์ PDF

Specifications | Stopper Cylinder RSQ / RSDQ / RSG / RSDG

TypeSeriesActionBore size(mm)
Fixed mounting height RSQ Double acting
Double acting with spring
Single acting, spring extend		 12, 16, 20, 32, 40, 50
Adjustable mounting height RSG Double acting
Double acting with spring
Single acting, spring extend		 40, 50

2) Heavy Duty Stopper Cylinder RS2H

SMC - Heavy Duty Stopper Cylinder RS2H
SMC - Heavy Duty Stopper Cylinder RS2H

Features | Heavy Duty Stopper Cylinder RS2H

  • Weight: Reduced by up to 22% (Compared with the previous RS1H series)
  • Cylinder tube: Shortened by up to 9 mm (RS2H63-30 stroke)
  • Capable of stopping pallets softly
  • Stopper cylinder with shock absorber
  • Lock Release specification (-XC102)
ดาวน์โหลดไฟล์ PDF

Specifications | Heavy Duty Stopper Cylinder RS2H

TypeSeriesActionBore size(mm)
Flange RS2H Double acting
Double acting with spring
Single acting, spring extend		 50, 63, 80

3) Heavy Duty Stopper Cylinder RSH

SMC - Heavy Duty Stopper Cylinder RSH
SMC - Heavy Duty Stopper Cylinder RSH

Features | Heavy Duty Stopper Cylinder RSH

  • Capable of stopping pallets softly
  • Stopper cylinder with shock absorber
ดาวน์โหลดไฟล์ PDF

Specifications | Heavy Duty Stopper Cylinder RSH

TypeSeriesActionBore size(mm)
Flange RSH Double acting
Double acting with spring
Single acting, spring extend		 20, 32

4) Escapements MIW / MIS

SMC - Escapements MIW / MIS
SMC - Escapements MIW / MIS

Features | Escapements MIW / MIS

Ideal for separating workpieces continuously moving on conveyors, etc.

ดาวน์โหลดไฟล์ PDF

Specifications | Escapements MIW / MIS

TypeSeriesActionBore size(mm)
2-finger type MIW Double acting 8, 12, 20, 25, 32
1-finger type MIS Double acting 8, 12, 20, 25, 32
